DATA SHEET ? SKY13353-337LF DPDT DIVERSITY SWITCH
1.150 +0.10/–0.15
C
Pin 1
3
A
B
(0.20)
S eating Plane
0.02 + 0.03/–0.02
Expo s ed Pad
1.000
0.575
Detail A
Indicator
0.575
2X
0.15 C
3
0.90 ± 0.10
1.000
Detail C
B
1.150 +0.10/–0.15
2X
0.15 C
0.10 C
12X 4
0.08 C
0.20 Min.
12X
A
Detail B
Top View
S ide View
Bottom View
R0.125 Typ.
0.18
0.55 +0.10
0.18
0.435
5
0.10 M C A B
0.435
Detail A
S cale: 20X
0.5
Detail B
S cale: 20X
0.25 +0.05/–0.07 0.05 M C
Detail C
S cale: 40X
12 Place s
All measurements are in millimeters.
Dimensioning and tolerancing according to ASME Y14.5M-1994.
Unilateral coplanarity applies to the exposed heat sink slug as well as the terminals.
Plating requirement per source control drawing (SCD) 2504.
Dimension applies to metallized terminal and is measured between 0.15 and 0.30 mm
from the terminal tip. Do not measure at radius area.
Figure 10. SKY13353-337LF 12-Pin QFN Package Dimensions
Skyworks Solutions, Inc. ? Phone [781] 376-3000 ? Fax [781] 376-3100 ? sales@skyworksinc.com ? www.skyworksinc.com
S1866
8
October 12, 2010 ? Skyworks Proprietary Information ? Products and Product Information are Subject to Change Without Notice ? 201376A
